Full complement needle track roller – yoke type

2004

Full complement needle track roller – yoke type is characterized by a thick outer ring that can directly rotate on the mating tracks.

Typically used when high load capacity and high shock resistance are required it can, also, support angular misalignments because of the particular geometry of the generatrix of the outer surface.

The axial guide (non-separable assembly) gives the roller the ability to support axial loads.

The full complement roller can support higher loads than the roller with cage, but the maximum operation speed is lower.

A watertight version is also available.

Some application fields

  • general handling

Alternative design

  • track roller for low and high temperatures applications
  • track roller employed in corrosive environments
  • in according to customer drawing
Production range mm
d
mm
D
mm
B
Min. value 5 16 32
Max. value 50 90 32
TTS - 2004 3d 1
TTS - 2004 2d

Download our catalogue.

Request further information
